Electrical Characteristics (TJ=25°C unless otherwise noted)
Min Typ Max Units
BVDSS Drain-Source Breakdown Voltage
IDSS Zero Gate Voltage Drain Current
IGSS Gate-Body leakage current
VDS=0V, VGS= ±30V
Gate Threshold Voltage
On state drain current
RDS(ON) Static Drain-Source On-Resistance
5.4 6.5 mΩ
6.6 8.1 mΩ
gFS Forward Transconductance
VSD Diode Forward Voltage
IS Maximum Body-Diode Continuous CurrentG
Ciss Input Capacitance
Coss Output Capacitance
Crss Reverse Transfer Capacitance
Rg Gate resistance
VGS=0V, VDS=12.5V, f=1MHz
VGS=0V, VDS=0V, f=1MHz
Qg(12V) Total Gate Charge
Qg(10V) Total Gate Charge
Qgs Gate Source Charge
VGS=10V, VDS=12.5V, ID=20A
Qgd Gate Drain Charge
Turn-On Rise Time
VGS=10V, VDS=12.5V, RL=0.63Ω,
tf Turn-Off Fall Time
trr Body Diode Reverse Recovery Time IF=20A, dI/dt=100A/µs
32 40 ns
Qrr Body Diode Reverse Recovery Charge IF=20A, dI/dt=100A/µs
A: The value of R θJA is measured with the device mounted on 1in 2 FR-4 board with 2oz. Copper, in a still air environment with
T A =25°C. The Power dissipation PDSM is based on t<10s R θJA and the maximum allowed junction temperature of 150°C. The value in any given
application depends on the user's specific board design, and the maximum temperature of 175°C may be used if the PCB allows it.
B. The power dissipation PD is based on TJ(MAX)=175°C, using junction-to-case thermal resistance, and is more useful in setting the upper
dissipation limit for cases where additional heatsinking is used.
C: Repetitive rating, pulse width limited by junction temperature TJ(MAX)=175°C.
D. The R θJA is the sum of the thermal impedence from junction to case R θJC and case to ambient.
E. The static characteristics in Figures 1 to 6 are obtained using <300 us pulses, duty cycle 0.5% max.
F. These curves are based on the junction-to-case thermal impedence which is measured with the device mounted to a large heatsink, assuming a
maximum junction temperature of TJ(MAX)=175°C. The SOA curve provides a single pulse rating.
G. The maximum current rating is limited by bond-wires.
H. These tests are performed with the device mounted on 1 in 2 FR-4 board with 2oz. Copper, in a still air environment with TA=25°C.
Re0: Sept. 2006
