A3197 - OPEN-COLLECTOR HALL-EFFECT LATCH

Features

  • Internal Protection For Automotive (ISO/DIN) Transients.
  • Operation From Unregulated Supply.
  • Reverse Battery Protection.
  • Undervoltage Lockout.
  • Supply Noise-Suppression Circuitry.
  • Output Short-Circuit Protection.
  • Output Zener Clamp.
  • Thermal Protection TA -40°C to +150°C.
  • Symmetrical Latching Switch Points Storage Temperature, TS 170°C.
  • Operable with Multipole Ring Magnets.
  • Fault condition, internal overvoltage shutdown above 28 V; outpu.

📥 Download Datasheet

Datasheet Details

Part number A3197
Manufacturer Allegro
File Size 588.38 KB
Description OPEN-COLLECTOR HALL-EFFECT LATCH
Datasheet download datasheet A3197 Datasheet

📁 Similar Datasheet

  • A3195 - HALL-EFFECT LATCH (Allegro MicroSystems)
  • A31 - highly integrated mobile application processor (Allwinner Technology)
  • A31-1 - 10 TO 2000 MHz CECASCADABLE AMPLIFIER (Tyco Electronics)
  • A310 - Triode (Philips)
  • A31101AP - COMPANDER IC (Toshiba Semiconductor)
  • A311D - advanced AI application processor (AMLOGIC)
  • A3121 - HALL-EFFECT SWITCHES FOR HIGH-TEMPERATURE OPERATION (Allegro MicroSystems)
  • A3122 - HALL-EFFECT SWITCHES FOR HIGH-TEMPERATURE OPERATION (Allegro MicroSystems)
  • A3123 - HALL-EFFECT SWITCHES FOR HIGH-TEMPERATURE OPERATION (Allegro MicroSystems)
  • A3130 - Universal DSP-Based PFC Solution (Alpha Microelectronics)
Other Datasheets by Allegro
  • A31004 - Unidirectional Linear Hall-Effect Sensor
  • A31010 - Low-Power Unidirectional Linear Hall-Effect Sensor
  • A31102 - Programmable Linear Hall-IC
  • A31301 - 3D Linear Hall-Effect Sensor
  • A31315 - 3D Magnetic Position Sensor
  • A3132 - Ultrasensitive Bipolar Hall Effect Switches
  • A3133 - Ultrasensitive Bipolar Hall Effect Switches
  • A3163 - Hall Effect Switch

Full PDF Text Transcription

Click to expand full text
Data Sheet 27609.10b 3197 PROTECTED, HIGH-TEMPERATURE, OPEN-COLLECTOR HALL-EFFECT LATCH These open-collector Hall-effect latches are capable of sensing magnetic fields while using an unprotected power supply. The A3197LLT and A3197LU can provide position and speed information by providing a digital output for X magnetic fields that exceed their predefined switch points. These devices PTCT operate down to zero speed and have switch points that are designed to be extremely stable over a wide operating temperature and voltage range. The V CC CT 1 2 3 OUTPUT GROUND SUPPLY PRODOUNLY Dwg. PH-003-2 D CE ABSOLUTE MAXIMUM RATINGS E N Supply Voltage, VCC (100 ms) ................................... 115 V* U E (continuous) ...............................
