D5V0L2B3W
D5V0L2B3W is 2 CHANNEL LOW CAPACITANCE BI-DIRECTIONAL TVS ARRAY manufactured by Diodes Incorporated.
ADVANCE INFORMATION
2 CHANNEL LOW CAPACITANCE BI-DIRECTIONAL TVS ARRAY
Features
- Provides ESD Protection per IEC 61000-4-2 Standard: Air
- ±30k V, Contact
- ±30k V
- 2 Channels of Bi-Directional ESD Protection
- Low Channel Input Capacitance
- Typically Used at Portable Electronics, Cellular Handsets and munication Systems
- Lead Free/Ro HS pliant (Note 1)
- “Green” Device (Note 2)
Mechanical Data
- Case: SOT323
- Case Material: Molded Plastic, “Green” Molding pound.
UL Flammability Classification Rating 94V-0
- Moisture Sensitivity: Level 1 per J-STD-020
- Terminals: Matte Tin Finish annealed over Alloy 42 leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
- Weight: 0.006 grams (approximate)
Top View
Ordering Information (Note 3)
12 Pin Configuration
D 5V0 L X B X XXX- XX
1 3
Device Schematic
Voltage
Capacitance
# of Channels
5V0: 5.0 Volts
X: Extremely Low (<0.5p F) F: Ultra Low (0.5 ~ 1.0p F) P:...
