DGD2184 Datasheet - Diodes

DGD2184, HALF-BRIDGE GATE DRIVER

The DGD2184 is a high voltage / high speed gate driver capable of driving N-Channel MOSFETs and IGBTs in a half bridge configuration. High voltage processing techniques enable the DGD2184’s high-side to switch to 600V in a bootstrap operation. The DGD2184 logic inputs are compatible with standard TT.

Datasheet Preview Page 1

DGD2184-Diodes.pdf

DGD2184 Datasheet Preview — Preview of DGD2184 PDF

DGD2184 Datasheet Preview Page 2

DGD2184 Datasheet Preview Page 3

Datasheet Details

Part number:

DGD2184

Manufacturer:

File Size:

892.15 KB

Description:

HALF-BRIDGE GATE DRIVER

DGD2184 Features

* Floating High-Side Driver in Bootstrap Operation to 600V

* Drives Two N-Channel MOSFETs or IGBTs in Half Bridge Configuration

* 1.4A Source / 1.8A Sink Output Current Capability

* Outputs Tolerant to Negative Transients

* Internal Dead Time of 395ns to Protect MOSFETs

* Wid
