SMAZ20
SMAZ20 is 1.0W SURFACE MOUNT ZENER DIODE manufactured by Diodes Incorporated.
- Part of the SMAZ5V1 comparator family.
- Part of the SMAZ5V1 comparator family.
Features
- 1.0W Power Dissipation
- Ideally Suited for Automated Assembly
- 5.1V
- 39V Nominal Zener Voltage Range
- Standard VZ Tolerance is ± 5%
- Lead Free Finish; RoHS pliant (Notes 1 & 2)
- Halogen and Antimony Free. “Green” Device (Note 3)
SMAZ5V1
- SMAZ39
Green
1.0W SURFACE MOUNT ZENER DIODE
Mechanical Data
- Case: SMA
- Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
- Moisture Sensitivity: Level 1 per J-STD-020
- Terminals: Lead Free Plating (Matte Tin Finish). Solderable per
MIL-STD-202, Method 208
- Polarity: Cathode Notch or Cathode Band
- Weight: 0.064 grams (Approximate)
Top View
Bottom View
Ordering Information (Note 4)
Device-...
