AZ23C10 Datasheet | Diodes Incorporated

Features - Dual Zeners in mon Anode Configuration - 300 m W Power Dissipation Rating - Ideally Suited for Automated Insertion - Δ VZ For Both Diodes in One Case is ≤ 5% - mon Cathode Style Available See DZ Series - Totally Lead-Free & Fully Ro HS pliant (Notes 1 & 2) - Halogen and Antimony Free. “Green” Device (Notes 3 & 4) - Qualified to AEC-Q101 Standards for High Reliability ESD Sensitivity Rating - AEC-Q101, HBM - 8k V, MM - 400V - IEC 61000-4-2, Air - 15k V, Contact - 8k V SOT23 AZ23C2V7 - AZ23C51 300m W DUAL SURFACE MOUNT ZENER DIODE Mechanical Data - Case: SOT23 - Case Material: Molded Plastic, “Green” Molding pound. UL Flammability Classification Rating 94V-0 - Moisture Sensitivity: Level 1 per J-STD-020 - Terminals: Matte Tin Finish annealed over Alloy 42 leadframe (Lead Free Plating). Solderable per MIL-STD-202, Method 208 - Polarity: See Diagram - Approximate Weight: 0.008 grams Top View Device Schematic Ordering Information (Note 5) Part Number (Type Number)-7-F- (Type Number)Q-7-F- Qualification mercial Automotive Case SOT23 SOT23 Packaging 3000/Tape & Reel 3000/Tape & Reel - Add “-7-F” to the appropriate type number in Electrical Characteristics Table on Page 2 example: 6.2V Zener = AZ23C6V2-7F Notes: 1. No purposely added lead. Fully EU Directive 2002/95/EC (Ro HS) & 2011/65/EU (Ro HS 2) pliant. 2. See http://.diodes. for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.  3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and <1000ppm antimony pounds. 4. Product manufactured with Date Code V9 (week 33, 2008) and newer are built with Green Molding pound. Product manufactured prior to...
