IXTQ150N15P
Features l International standard packages l Unclamped Inductive Switching (UIS) rated l Low package inductance
- easy to drive and to protect
Advantages l Easy to mount l Space savings l High power density
© 2006 IXYS All rights reserved
DS99299E(03/06)
Symbol g fs
Ciss Coss Crss td(on) tr td(off) tf Qg(on) Qgs Qgd R th JC
Rth CK Rth CS
Test Conditions
Characteristic Values
(TJ = 25° C, unless otherwise specified) Min. Typ. Max.
V = 10 V; I = 0.5 I , pulse test
55 80
D25
VGS = 0 V, VDS = 25 V, f = 1 MHz
5800 p F
1730 p F
400 p F
VGS = 10 V, VDS = 0.5 VDSS, ID = ID25 RG = 3.3 Ω (External)
30 ns
33 ns
100 ns
28 ns
VGS= 10 V, VDS = 0.5 VDSS, ID = 0.5 ID25
190 n C
40 n C
105 n C
TO-3P TO-264
0.21 0.15
0.21° C/W ° C/W ° C/W
IXTK 150N15P IXTQ 150N15P
TO-264 (IXTK) Outline
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25° C, unless otherwise specified) Min. Typ....
