LM238WF1-SLK1 Datasheet | LG Electronics

Description LM238WF1 is a Color Active Matrix Liquid Crystal Display with a Light Emitting Diode(WLED) backlight system without LED driver. The matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in the normally black mode. It has a 23.8 inch diagonally measured active display area with FHD resolution (1080 horizontal by 1920 vertical pixels array) Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale signal for each dot, thus, presenting a palette of more than 16.78 Million/Billion colors. It has been designed to apply the 8-bit 2port LVDS interface. It is intended to support displays where high brightness, super wide viewing angle, high color saturation, and high color are important. LVDS 2port CN1 (30pin) +5.0V EEPROM I2C Timing Controller Logic Power +5.0V Power Circuit Block G1 - LCD Panel × × (1920 RGB 1080 pixels) G1080 S1 S1920 Source Driver Circuit VLED General Features Active Screen Size Outline Dimension Pixel Pitch Pixel Format Color Depth Luminance, White Viewing Angle(CR>10) Power Consumption Weight Display Operating Mode Panel type Surface Treatment Ver. 1.0 CN2 (6PIN) Back light Assembly (LED) [ Figure 1 ] Block diagram 23.8 inches(604.70mm) diagonal 543.0(H) x 317.4(V) x 11.2(D) mm (Typ.) 0.2745 mm x 0.2745 mm 1920 horiz. By 1080 vert. Pixels RGB stripes arrangement 16.78M colors (6bit + A-FRC) 250 cd/m2 ( Center 1 Point, Typ.) View Angle Free (R/L 178(Typ.), U/D 178(Typ.)) Total 12.2 Watt (Typ.) (2.3 Watt @VLCD, 9.9 Watt @Is= 90 m A ) 2,000 g (typ.) Transmissive mode, normally black Reverse type Hard coating(3H), Anti-glare treatment of the front polarizer Mar. 24. 2016 4 / 33 Product Specification LM238WF1 Liquid Crystal Display 2. Absolute Maximum Ratings The following are maximum values which, if exceeded, may cause...
