LD1010D - High Performance N-Channel POWERJFET

Datasheet Details

Part number	LD1010D
Manufacturer	Lovoltech
File Size	657.77 KB
Description	High Performance N-Channel POWERJFET
Datasheet	LD1010D_Lovoltech.pdf

The Power JFET transistor from Lovoltech is a device that presents a Low Rdson allowing for improved efficiencies in DCDC switching applications.

Trench Power JFET with low threshold voltage Vth. Device fully “ON” with Vgs = 0.7V Optimum for “Low Side” Buck Converters Optimized for Secondary Rectification in isolated DC-DC Low Rg and low Cds for high speed switching www. DataSheet4U. com No “Body Diode”; extremely low Cds Added Fast Recovery Schottky Diode in same package.
