AXIAL LEAD TRANSIENT VOLTAGE SUPPRESSORS
SA5.0 - SA440CA
DIMENSION
DO-15
Dim Millimeters
Inches
Min Max Min Max
A 25.4 --- 1.000 ---
B 5.80 7.60 0.230 0.300
C 0.70 0.90 0.028 0.034
D 2.60 3.60 0.104 0.140
SPECIFICATION
Type Number
(Uni)
SA5.0
SA5.0A
SA6.0
SA6.0A
SA6.5
SA6.5A
SA7.0
SA7.0A
SA7.5
SA7.5A
SA8.0
SA8.0A
SA8.5
SA8.5A
SA9.0
SA9.0A
SA10
SA10A
SA11
SA11A
SA12
SA12A
SA13
SA13A
(Bi)
SA5.0C
SA5.0CA
SA6.0C
SA6.0CA
SA6.5C
SA6.5CA
SA7.0C
SA7.0CA
SA7.5C
SA7.5CA
SA8.0C
SA8.0CA
SA8.5C
SA8.5CA
SA9.0C
SA9.0CA
SA10C
SA10CA
SA11C
SA11CA
SA12C
SA12CA
SA13C
SA13CA
Reverse
Stand-Off
Voltage
VRMW(V)
5.0
5.0
6.0
6.0
6.5
6.5
7.0
7.0
7.5
7.5
8.0
8.0
8.5
8.5
9.0
9.0
10
10
11
11
12
12
13
13
Breakdown
Voltage
Min. @IT
VBR MIN(V)
6.40
6.40
6.67
6.67
7.22
7.22
7.78
7.78
8.33
8.33
8.89
8.89
9.44
9.44
10.0
10.0
11.1
11.1
12.2
12.2
13.3
13.3
14.4
14.4
Breakdown
Voltage
Max. @ IT
VBR MAX(V)
7.30
7.00
8.15
7.37
8.82
7.98
9.51
8. 60
10.2
9.21
10.9
9.83
11.5
10.4
12.2
11.1
13.6
12.3
14.9
13.5
16.3
14.7
17.6
15.9
Test
Current
IT (mA)
10
10
10
10
10
10
10
10
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Maximum
Clamping
Voltage
@IPP
VC(V)
9.6
9.2
11.4
10.3
12.3
11.2
13.3
12.0
14.3
12.9
15.0
13.6
15.9
14.4
16.9
15.4
18.8
17.0
20.1
18.2
22.0
19.9
23.8
21.5
Peak
Pulse
Current
IPP(A)
53.1
55.4
44.7
49.5
41.5
45.5
39.3
42.5
35.7
39.5
34.0
37.5
32.1
35.4
30.2
33.1
27.1
30.0
25.4
28.0
23.2
25.6
21.4
23.7
Reverse
Leakage
@VRMW
IR(uA)
600.0
600.0
600.0
600.0
400.0
400.0
150.0
150.0
50.0
50.0
25.0
25.0
10.0
10.0
5.0
5.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
For Bi-directional type having VRWM of 10 Volts and less, the IR limit is double
