MAX17290 - PWM Boost Controller

Description

The MAX17290/MAX17292 high-efficiency, synchronous step-up DC-DC controllers operate over a 4.5V to 36V input voltage range with 42V input transient protection.

The input operating range can be extended to as low as 2.5V in Bootstrapped mode.

Features

  • Reduces Solution Size and Cost.
  • All-Ceramic Capacitor Solution Allows Ultra-Compact Solution Size.
  • 100kHz to 1MHz (MAX17290) and 1MHz to 2.5MHz (MAX17292) Switching-Frequency with External Synchronization.
  • Increases Design Flexibility.
  • Bootstrapped Mode Allows Input Voltage to be 2.5V.
  • Adjustable Slope Compensation.
  • Reduces Power Dissipation.
  • >90% Peak Efficiency.
  • Low 4μA (typ. ) Shutdown Current.
