MAX7442, MAX7440, (MAX7440 - MAX7442) 6-Channel Integrated Video Reconstruction Filters

The MAX7440/MAX7441/MAX7442 six-channel video reconstruction filters replace 30 or more discrete components. The devices are ideal for digital-to-analog converter (DAC) video reconstruction applications, when analog video is reconstructed from a digital data stream. The MAX7440/MAX7441/MAX7442 opera.

MAX7440_MaximIntegratedProducts.pdf

MAX7442 Datasheet Preview — This datasheet PDF includes multiple part numbers: MAX7442, MAX7440. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

MAX7442, MAX7440

Manufacturer:

Maxim Integrated ↗ Products

File Size:

250.54 KB

Description:

(MAX7440 - MAX7442) 6-Channel Integrated Video Reconstruction Filters

Note:

This datasheet PDF includes multiple part numbers: MAX7442, MAX7440.
Please refer to the document for exact specifications by model.

MAX7442 Features

* o Replace 30 or More Discrete Components o Ideal for CVBS, Y/C (S-Video), and RGB or Y Pb Pr Applications o 45dB Attenuation at 27MHz o -0.2dB Passband Response o Ideal for STBs with SCART Interface o +5V Single-Supply Voltage o Input Common-Mode Range Includes GND o DC-Coupled Input, DC/AC-Coupled
