CDR31BP111BW
..
Metuchen Capacitors,Inc.
1-888-535-1535
- 732-888-9700 1-800-679-9959/Fax .metcaps.
Toll Free
“We Offer Quick Solutions to Noise Pollution”
Ceramic Chip/MIL-C-55681
Established Reliability
“SOLDERGUARD” II
TINNED
“SOLDERGUARD” I
SOLDER
.020±.010 (.51±.25) T NICKEL SILVER METALLIZATION FOR SOLDER REFLOW ASSEMBLY TERMINATIONS (METALLIZATION BANDS) ELECTRODES FOR SOLDER REFLOW ASSEMBLY NICKEL SILVER METALLIZATION ELECTRODES
MILITARY DESIGNATION “S” OR “U”
MILITARY DESIGNATION “W” OR “Y”
Dimensions- Millimeters & (Inches)
Style CDR01 CDR02 CDR03 CDR04 CDR05 CDR06 CDR31 CDR32 CDR33 CDR34 CDR35 Size Code C0805 C1805 C1808 C1812 C1825 C2225 C0805 C1206 C1210 C1812 C1825 T L 2.03±.38 (.080±.015) 4.57±.38 (.180±.015) 4.57±.38(.180±.015) 4.57±.38 (.180±.015) 4.57+.51 (1.80+.020) -.38 ( -.015) 5.72±.51 (.225±.020) 2.00±.20 (.078±.008) 3.20±.20 (.125±.008) 3.20±.25 (.125±.010) 4.50±.25 (.176±.010) 4.50±.30 (.176±.012) W 1.27±.38 (.050±.015) 1.27±.38 (.050±.015) 2.03±.38 (.080±.015)...
