LM350 Datasheet - National Semiconductor

Dual Peripheral Drivers

LM350 Features

* High speed

* High sink current 300 mA

* Separate gates and transistors

* Both transistors can sink 300 mA simulta- neously

* Transistors withstand 30V collector to emitter in the OF F state

* Input clamp diodes sr-: w oc.n schematic and connection

LM350 General Description

The LM75450 and LM350 are general purpose dual peripheral drivers. The design employs two standard TTL gates (NOR in LM350, NAND in LM75450) and two totally uncommitted, hlghvoltage, high-current NPN transistors. These transistors are capable of sinking 300 mA and will withstand 30V in the OFF state.

LM350 Datasheet (114.10 KB)

Preview of LM350 PDF

Datasheet Details

Part number:

LM350

Manufacturer:

National Semiconductor

File Size:

114.10 KB

Description:

Dual peripheral drivers.
