Space-saving SSOP 1 Form A type with built-in registor
40V load voltage
RF SSOP C×R10
Voltage-sensitive (AQY221F❍2V)
2.65 4.45 .104 .175
1.80 .071
mm inch
14
23
RoHS compliant
FEATURES
1. Built-in input resistor means less man-hours when mounting The voltage-sensitive type, which eliminates the need to mount an external input resistor, is now available in a small package. Man-hours spent mounting external input resistors are cut and board designing is simplified. 2. Save space on PC board Since the small package size remains the same while including a built-in input resistor, space on the PC board is saved. This makes it easier to incorporate space savings when designing miniature devices.
Existing way of mounting external resistors
With resistors built in
Space saved
3.
