POWER CHOKES, SMD PANASONIC type PCC-N6
EMC, FILTERS & SUPPRESSION
Surface mount power choke coils in a compact package with a height of only 5.7mm. The chokes have a saturation current capability of up to 25A and are available in a range of inductance values from 1.8µH to 12.5µH. Designed for use in DC/DC converters and power supplies, the devices are supplied taped and reeled.
N N N N N N N
High power Saturation current up to 25A Inductance values from 1.8µH to 12.5µH Low profile and compact Low leakage flux For DC/DC converters and power supplies Supplied taped & reeled 5.7mm high
Specification
Inductance tolerance ≤4.1µH ....................................................... ±30% >4.1µH ....................................................... ±25% Test frequency...................
