RF2056, HIGH PERFORMANCE VHF/UHF PLL AND VCO

* * * * * Applications * * * * * * VHF/UHF Radios Super-Heterodyne Radios Diversity Receivers Wireless Telemetry PMR Marine Radios N The RF2056 is a low power, high performance, VHF/UHF frequency conversion chip with integrated local oscillator (LO.

RF2056-RFMD.pdf

RF2056 Datasheet Preview — Preview of RF2056 PDF

Datasheet Details

Part number:

RF2056

Manufacturer:

RFMD

File Size:

1.77 MB

Description:

HIGH PERFORMANCE VHF/UHF PLL AND VCO

RF2056 Features

* VCO LO divider Fractional-N Synthesizer Very Fine Frequency Resolution 1.5Hz for 26MHz Reference LO Frequency Range Between 50MHz and 500MHz Low Phase Noise VCO VCO Range 200MHz to 500MHz Dependent on External Inductor Integrated LO Buffers and LO Dividers On-Chip Crystal-Sustaining Ci
