SM8S16CA - Surface Mount Transient Voltage Suppressors

This page provides the datasheet information for the SM8S16CA, a member of the SM8S10 Surface Mount Transient Voltage Suppressors family.

Datasheet Summary

Description

SM8S Series TVS diodes can be used in sensitive electronics protection against voltage transients induced by inductive load switching and lighting, especially for automotive load dump protection application.

Features

  • Available in uni/bi-directional polarity.
  • Low forward voltage drop & Low leakage current.
  • High surge capability.
  • Junction passivation optimized design passivated anisotropic rectifier technology.
  • TJ = 175 ℃ capability suitable for high reliability and automotive requirement.
  • Meets ISO7637-2 surge specification (varied by test condition).
  • Meets MSL level 1, per J-STD-020,LF maximum peak of 245℃.
  • AEC-Q101 qualified.
  • Compliant to RoHS Directive.

📥 Download Datasheet

Datasheet preview – SM8S16CA

Datasheet Details

Part number SM8S16CA
Manufacturer SOCAY
File Size 1.43 MB
Description Surface Mount Transient Voltage Suppressors
Datasheet download datasheet SM8S16CA Datasheet
Additional preview pages of the SM8S16CA datasheet.

📁 Similar Datasheet

  • SM8S16CA - 6600W Transient Voltage Suppressor (Leiditech)
  • SM8S16CA - TRANSIENT VOLTAGE SUPPRESSOR (ZEN ELECTRONIC)
  • SM8S16CA - TVS (MCC)
  • SM8S16CA - Surface Mount Transient Voltage Suppressor (Semiware)
  • SM8S16CA - Transient Voltage Suppressor Diode (BOURNS)
  • SM8S16CA - Surface Mount Transient Voltage Suppressors (JIEJIE)
  • SM8S16CA - SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR (EIC)
  • SM8S16CA - Transient Voltage Suppressors (Vishay)
  • SM8S16C - SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR (EIC)
  • SM8S16 - Transient Voltage Suppressor Diode (Yint)
Other Datasheets by SOCAY
  • SM8S16 - Surface Mount Transient Voltage Suppressors
  • SM8S16A - Surface Mount Transient Voltage Suppressors
  • SM8S10 - Surface Mount Transient Voltage Suppressors
  • SM8S10A - Surface Mount Transient Voltage Suppressors
  • SM8S10CA - Surface Mount Transient Voltage Suppressors
  • SM8S11 - Surface Mount Transient Voltage Suppressors
  • SM8S11A - Surface Mount Transient Voltage Suppressors
  • SM8S11CA - Surface Mount Transient Voltage Suppressors

Full PDF Text Transcription

Click to expand full text
6600W Transient Voltage Suppressor (TVS) SM8S Series 10 To 43 V 6600W Description SM8S Series TVS diodes can be used in sensitive electronics protection against voltage transients induced by inductive load switching and lighting, especially for automotive load dump protection application. DO-218AB Features  Available in uni/bi-directional polarity.  Low forward voltage drop & Low leakage current.  High surge capability.  Junction passivation optimized design passivated anisotropic rectifier technology.  TJ = 175 ℃ capability suitable for high reliability and automotive requirement.  Meets ISO7637-2 surge specification (varied by test condition).  Meets MSL level 1, per J-STD-020,LF maximum peak of 245℃.  AEC-Q101 qualified.
