DESCRIPTION DESCRIPTION LTM190U1-L01 is a color active matrix TFT (Thin Film Transistor) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching devices. This model is posed of a TFT LCD panel, a driver circuit and a backlight system. The resolution of a 19.0" contains 1600 x 1200 pixels and can display up to 16.7 million colors with wide viewing angle of 85 degrees or higher in all directions. (Vertical viewing angle : 170 degrees , Horizontal viewing angle : 170 degrees ) FEATURES - High contrast ratio, high aperture structure - APVA (Advanced Patterned Vertical Alignment) mode - Wide viewing angle - High speed response - UXGA ((1600x1200) pixels) resolution - Low power consumption - 2 dual CCFT (Cold Cathode Fluorescent Tube) - DE (Data enable) only mode. - LVDS (Low Voltage Differential Signaling) Interface (2 pixel / clock) APPLICATIONS - Workstation & desktop monitors - Display terminals for AV application products - Monitors for Industrial machine Doc.No. PI001_LTM190U1-L01 Page /7 ..net ..net GENERAL INFORMATION ITEM Display area Driver element Display colors Number of pixels Pixel arrangement Pixel pitch Display Mode Surface treatment SPECIFICATION 386.4(H)X289.8(V) a-Si TFT active matrix 16.7M (true) 1600 x 1200 RGB vertical stripe 0.2415(H) x 0.2415(W) Normally Black HAZE 25%, HARD-COATING (3H) mm colors pixel UNIT mm NOTE Mechanical Information ITEM Horizontal (H) Module size Vertical (V) Depth (D) Weight MIN. 414.5 325.5 TYP. 415.0 326.0 MAX. 415.5 326.5 26.5 3,000 NOTE mm mm mm g Doc.No. PI001_LTM190U1-L01 Page /7 ..net ..net INPUT Interface Connection Connector : JAE FI-WE31P-HF PIN NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 A7M A7P NC NC NC NC NC Negative LVDS differential data output Positive LVDS differential data output Reserved Reserved Reserved Reserved Reserved A4M A4P A5M A5P A6M A6P GND GND CLKM CLKP A3M A3P GND Ground Negative LVDS differential clock...
