Ordering number : ENA0643
LA71578HM
Monolithic Linear IC
For VHS VCR
Video Audio Signal Processor
(Y/C/A/HA SINGLE-CHIP)
Overview
This LA71578HM is Video Audio Signal Processor for VHS VCR (Y/C/A/HA SINGLE-CHIP).
Specifications
Maximum Ratings at Ta = 25°C
Parameter Maximum supply voltage Allowable power dissipation Operating temperature Storage temperature
Symbol VCC
Pd max Topg Tstg
* Mounted on a board : 70× 70×1.6mm3, paper phenol.
Conditions Pins 40, 16, 58, 87, 55, 75 Ta≤65°C *
Recommended Operating Conditions at Ta = 25°C
Parameter Recommended supply voltage Allowable operating voltage range
Symbol VCC
VCC opg
Conditions Pins 40, 16, 58, 87, 55, 75 Pins 40, 16, 58, 87, 55, 75
Ratings
Unit
7.0
V
1400
mW
-10 to +65
°C
-40 to +150
°C
Ratings
Unit
5.0
V
4.
LA71578HM Datasheet
