THN15-1210 Datasheet | TRACO

features include remote On/Off and trimmable output. Typical applications for these converters are mobile equipment, instrumentation, distributed power architectures in munication and industrial electronics and everywhere where space on PCB is critical. Models Order Code THN 15-1210 THN 15-1211 THN 15-1212 THN 15-1213 THN 15-1215 THN 15-1221 THN 15-1222 THN 15-1223 THN 15-1225 THN 15-2410 THN 15-2411 THN 15-2412 THN 15-2413 THN 15-2415 THN 15-2421 THN 15-2422 THN 15-2423 THN 15-2425 THN 15-4810 THN 15-4811 THN 15-4812 THN 15-4813 THN 15-4815 THN 15-4821 THN 15-4822 THN 15-4823 THN 15-4825 Input Voltage Range - 18 VDC (12 VDC nom.) - 36 VDC (24 VDC nom.) - 75 VDC (48 VDC nom.) Output 1 Vnom Imax 3.3 VDC 5 VDC 12 VDC 15 VDC 24 VDC +5 VDC +12 VDC +15 VDC +24 VDC 4'000 m A 3'000 m A 1'300 m A 1'000 m A 625 m A 1'500 m A 625 m A 500 m A 315 m A 3.3 VDC 5 VDC 12 VDC 15 VDC 24 VDC +5 VDC +12 VDC +15 VDC +24 VDC 4'000 m A 3'000 m A 1'300 m A 1'000 m A 625 m A 1'500 m A 625 m A 500 m A 315 m A 3.3 VDC 5 VDC 12 VDC 15 VDC 24 VDC +5 VDC +12 VDC +15 VDC +24 VDC 4'000 m A 3'000 m A 1'300 m A 1'000 m A 625 m A 1'500 m A 625 m A 500 m A 315 m A Output 2 Vnom Imax - 5 VDC - 12 VDC - 15 VDC - 24 VDC 1'500 m A 625 m A 500 m A 315 m A - 5 VDC - 12 VDC - 15 VDC - 24 VDC 1'500 m A 625 m A 500 m A 315 m A - 5 VDC - 12 VDC - 15 VDC - 24 VDC 1'500 m A 625 m A 500 m A 315 m A Efficiency typ. 84 % 88 % 86 % 88 % 90 % 85 % 87 % 88 % 90 % 86 % 88 % 87 % 88 % 90 % 85 % 88 % 88 % 90 % 86 % 88 % 88 % 88 % 91 % 85 % 89 % 88 % 91...
