MC201 Serial Converter Introduction

Power is being supplied/working well ◎ Environment: Working Temperature: -40~85℃ Humidity: 5%~95% ◎ Installation Type: Wall-mount and Panel-mount Interface Type: single optical port or dual optical port, SC/ST/FC optional Fiber Type: single-model/multi-model Wavelength: 1310nm POWER off Power i.

【Introduction】 MC201 is a CAN bus to fiber converter. It designs specially to deal with the short transmission distance of CAN bus, the subjection to electromagnetic interference and other issues. CAN bus transfer to fiber is able to provide the user with transparent data transmission of CAN bus to fiber. It is working in pairs, is more convenient to put the CAN signal revert to the CAN signal through fiber transmission. MC201 serial converter integrates an optical interface and a 2KVAC electric.

MC201 Features

* ◇ Support CAN2.0A and CAN2.0B protocol, conform to the ISO/DIS 11898 ◇ Integrate1 UTD CAN interface and 1 optical interface ◇ CAN interface supports auto-detect baud rate and user-defined baud rate, the baud rate matches the range of 2.5k~1Mbps ◇ Support optic fiber transmit CAN network data ◇ Exte
