AF7243M

350mA Low Power LDO

AF7243M Features

* Low voltage drop: 0.17V@100mA

* High input voltage: 18V

* Low temperature coefficient

* Large Output Current: >0.35A Applications

* Battery-powered equipment

* Hand-Hold Equipment

* Low Quiescent Current: 1.0uA

* Output voltage accuracy: tolerance ±2%

* Built-i

AF7243M General Description

The AF72XXM series is a group of positive voltage output, three-pin regulators, that provide a high current even when the input/output voltage differential is small. Low power consumption and high accuracy is achieved through CMOS and laser trimming technologies. The AF72XXM consists of a high-prec.

AF7243M Datasheet (1.01 MB)

Preview of AF7243M PDF

Datasheet Details

Part number:

AF7243M

Manufacturer:

AFSEMI

File Size:

1.01 MB

Description:

350ma low power ldo.
