Description
AN5x is a family of AND-NOR circuits consisting of one 3-input AND gate and one 2-input AND gate into a 2-input NOR gate.
Logic Symbol
Truth Table
A
AN5x
ABCDEQ
B HHHXX L C
Q XXXHHL
D
All other combinations
H
E
Core Logic
HDL Syntax Verilog .................... AN5x inst_name (Q, A, B, C, D, E); VHDL...................... inst_name: AN5x port map (Q, A, B, C, D, E);
Pin Loading
Pin Name
A B C D E
AN52 1.0 1.0 1.0 1.0 1.0
Equivalent Loads AN54 1.0 1.0 1.0 1.0 1.0
AN56 2.1 2.1 2.1 2.2 2.2
Size And Power Characteristics
Power Characteristicsa
Cell Equivalent Gates
Static IDD (TJ = 85°C) (nA)
EQLpd (Eq-load)
AN52
4.0
TBD
8.0
AN54
5.0
TBD
9.4
AN56
12.0
TBD
18.6
a. See page 2-15 for power equation.
AN52 Datasheet
