ATM2412BS - LIQUID CRYSTAL DISPLAY

Name: ATM2412BS
SKU: ATM2412BS-1585831

AZ Displays

📥 Download Datasheet

ATM2412BS Datasheet Preview — Preview of ATM2412BS PDF

Datasheet Details

Part number	ATM2412BS
Manufacturer	AZ Displays
File Size	409.55 KB
Description	LIQUID CRYSTAL DISPLAY
Datasheet	ATM2412BS-AZDisplays.pdf

ATM2412BS Product details

Description

AZ DISPLAYS 2 ATM2412BS SERIES TFT GRAPHIC MODULE VER1.3 1.0 GENERAL SPECS ATM2412BS series design is based on ZETTLER patented HC product ATM2412B/BA series.Besides all the

Features

of ATM2412B/BA series, this product adopts SPI interface which can greatly save user’s MCU resource. Traditional 240.
128 mono products require 15 MCU GPIOs while ATM2412BS series require only 5 GPIOs. Furthermore, ATM2412BS integrates more functions into this SPI interface, now user can control font/column setting via SPI interface, and user can even change the font/background color and control the backlight brightness via this SPI interface without consuming extra hardware/software resource.
