KMA010-xxx
Features
:
- Supplied in high temperature Peel-A-Way® removable terminal carrier.
- Sockets and adapters are designed in mating pairs.
- 2 mm (.079”) centers pin to pin.
- High reliability screw machine terminals with closed end construction for 100% antiwicking of solder.
- For surface mount board to board options consult factory.
P/N Ex. KMA010-165G m o c
Board to Board Interconnections
Single Row KMA
- Male / KMS
- Female
.079 Typ. (2 mm) .100 Typ. (2.54)
Terminals and Contacts:
Terminal: Brass
- Copper Alloy (C36000), ASTM-B-16 Contact: Beryllium Copper
- Copper Alloy (C17200), ASTM-B-194
Plating:
Terminal: Gold over Nickel or Tin-Lead over Nickel Contact: Gold over Nickel or Tin-Lead over Nickel
Body Material:
Polyimide Film, Temp. range -269˚C to 400˚C (-452˚F to 752˚F) w w w
.D
T t a
S a e h
Single
Triple Row KMC
- Male / KMT
- Female
P/N Ex. KMC030-165T t e
U 4
.c
Dual Row KMB
- Male / KMD
- Female
P/N Ex. KMD020-85GG m...
