ACT4438 Datasheet, Transceiver, Aeroflex

ACT4438 Features

• Transceiver ❑ Transceiver meets MIL-STD-1553 and MIL-STD-1760 ❑ Low power dissipation at full output power ❑ Single +5V power supply ❑ Receiver threshold control ❑ Current Source Transmitter Output

PDF File Details

Part number:

ACT4438

Manufacturer:

Aeroflex

File Size:

205.84kb

Download:

📄 Datasheet

Description:

Transceiver. The Aeroflex Plainview Model ACT4438 is a next generation monolithic transceiver which provide full compliance with MIL-STD-1553/1760

ACT4438 Application

• Applications ❑ Integral heat sink ❑ Miniature Chipscale Package: QFN, Epad, 52 lead, 8 x 8 mm Weight: 0.2g GENERAL DESCRIPTION The Aeroflex Plainvie
