MV1650 Silicon Abrupt Varactors

Silicon Abrupt Varactors: General Purpose Glass Axial Leaded MV1620 MV1650 Model MV1620 MV1622 MV1624 MV1626 MV1628 MV1630 MV1632 MV1634 MV1636 MV1638 MV1640 MV1642 MV1644 MV1646 MV1648 MV1650 Test Conditions MIN 6.1 7.4 9.0 10.8 13.5 16.2 18.0 19.8 24.3 29.7 35.1 42.3 50.4 61.2 73.8 90.0 Diode Capacitance CT pF TYP 6.8 8.2 10.0 12.0 15.0 18.0 20.0 22.0 27.0 33.0 39.0 47.0 56.0 68.0 82.0 100.0 Vr = 4 Vdc, F = 1 MHz MAX 7.5 9.0 11.0 13.2 16.5 19.8 22.0 24.2 29.7 36.3 42.9 51.7 61..

MV1650 Datasheet (56.70 KB)

MV1650 Datasheet Preview — Preview of MV1650 PDF

Datasheet Details

Part number:

MV1650

Manufacturer:

Aeroflex

File Size:

56.70 KB

Description:

Silicon abrupt varactors.
