5082-7302 Datasheet, Indicators, Agilent Technologies

5082-7302 Features

• Indicators
• Numeric 5082-7300/-7302 0-9, Test State, Minus Sign, Blank States Decimal Point 7300 Right Hand D.P. 7302 Left Hand D.P.
• Hexadecimal 5082-7340 0-9, A-F, Base 16 Oper

PDF File Details

Part number:

5082-7302

Manufacturer:

Agilent Technologies

File Size:

228.18kb

Download:

📄 Datasheet

Description:

(5082-73xx) hexadecimal and numeric indicators. Agilent’s 5082-7300 series solid state numeric and hexadecimal indicators with on-board decoder/ driver and memory provide 7.4 mm (0.

5082-7302 Application

• Applications include terminals and computer systems using the base16 character set. The 5082-7304 is a (± 1) overrange display including a righthand
