HCPL-7840 Datasheet, Amplifier, Agilent

HCPL-7840 Features

• Amplifier
• 15 kV/µs Common-Mode Rejection at VCM = 1000 V
• Compact, Auto-Insertable Standard 8-pin DIP Package
• 0.00025 V/V/°C Gain Drift vs. Temperature
• 0.3

PDF File Details

Part number:

HCPL-7840

Manufacturer:

Agilent

File Size:

240.95kb

Download:

📄 Datasheet

Description:

Isolation amplifier. The HCPL-7840 isolation amplifier family was designed for current sensing in electronic motor drives. In a typical implementation, mo

HCPL-7840 Application

• Applications
• Motor Phase and Rail Current Sensing
• Inverter Current Sensing
• Switched Mode Power Supply Signal Isolation
