2540 Datasheet, Driver, Allegro

2540 Features

• Driver s 1.8 A Continuous Output Current s Output Voltage to 50 V s TTL and 5 V CMOS Compatible Inputs s Efficient Input/Output Pinning s Integral Transient-Suppression Diodes s Replaces L6221

PDF File Details

Part number:

2540

Manufacturer:

Allegro

File Size:

100.20kb

Download:

📄 Datasheet

Description:

Quad darlington power driver.

2540 Application

• Applications include print heads, relays, solenoids, and dc stepping motors. These drivers can also be used to drive highcurrent incandescent lamps,
