UCN5810AF Datasheet, Drivers, Allegro

UCN5810AF Features

• Drivers s High-Speed Source Drivers s 60 V Minimum Output Breakdown s Improved Replacements for TL4810B s Low Output Saturation Voltages s Low-Power CMOS Logic and Latches s To 3.3 MHz Data In

PDF File Details

Part number:

UCN5810AF

Manufacturer:

Allegro

File Size:

103.78kb

Download:

📄 Datasheet

Description:

Latched source drivers.

UCN5810AF Application

• Applications The UCN5810AF/LWF feature reduced supply requirements (active DMOS pulldowns) and lower saturation voltages when compared with the ori
