AOT426 - N-Channel MOSFET

Alpha & Omega Semiconductors

Datasheet Details

Part number	AOT426
Manufacturer	Alpha & Omega Semiconductors
File Size	243.02 KB
Description	N-Channel MOSFET
Datasheet	AOT426_AlphaOmegaSemiconductors.pdf

The AOT426 uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge.

VDS (V) = 30V ID = 85A RDS(ON) < 6mΩ (VGS = 10V) RDS(ON) < 11mΩ (VGS = 4.5V) DataShee DataSheet4U. com G D S G S Absolute Maximum Ratings TA=25°C unless otherwise noted Parameter Symbol VDS Drain-Source Voltage VGS Gate-Source Voltage Continuous Drain Current G Pulsed Drain Current Avalanche Current C C C Maximum 30 ±20 85 62.5 200 30 45 75 37.5 -55 to 175 Units V V A A mJ W °C TC=25°C TC=100°C ID IDM IAR EAR PD TJ, TSTG TC=25°C Repetitive avalanche energy L=0.1mH Power Dissipation B TC=1.
