AD7948 Datasheet, Dacs, Analog Devices

✔ AD7948 Features

12-Bit Multiplying DACs Guaranteed Specifications with +3.3 V/+5 V Supply 0.5 LSBs INL and DNL Low Power: 5 ␮ W typ Fast Interface 40 ns Strobe Pulsewidth (AD7943) 40 ns

✔ AD7948 Application

Battery-Powered Instrumentation Laptop Computers Upgrades for All 754x Series DACs (5 V Designs) VREF CLR LD

PDF File Details

Analog Devices manufacturer logo and representative part image

Part number:

AD7948

Manufacturer:

Analog Devices ↗

File Size:

329.86kb

Download:

📄 Datasheet

Description:

+3.3 v/+5 v multiplying 12-bit dacs. The AD7943, AD7945 and AD7948 are fast 12-bit multiplying DACs that operate from a single +5 V supply (Normal Mode) and a single +3.

📥 Download PDF (329.86kb)
