ADL5505 datasheet, detector equivalent, Analog Devices

ADL5505 Features and benefits

True rms response detector Excellent temperature stability ±0.25 dB rms detection accuracy vs. temperature Over 35 dB input power dynamic range, inclusive of crest factor.

ADL5505 Application

Power measurement of W-CDMA, CDMA2000, QPSK-/QAMbased OFDM (LTE and WiMAX), and other complex modulation waveforms RF tr.

ADL5505 Description

The ADL5505 is a TruPwr™ mean-responding (true rms) power detector for use in high frequency receiver and transmitter signal chains from 450 MHz to 6000 MHz. Requiring only a single supply between 2.5 V and 3.3 V, the detector draws less than 1.8 mA..

Image gallery
