LD501 datasheet, regulator equivalent, AnalogySemi

LD501 Features and benefits

* Ultra-low noise: 13.5μV rms at VOUT = 3.3V 9.5µV rms at VOUT = 1.1V
* No noise bypass capacitor required
* Stable with 1μF ceramic input and output capacito.

LD501 Application

* RF, voltage controlled oscillator (VCO), and phase locked loop (PLL) power supplies
* Mobile phones
* Digi.

LD501 Description

The LD501 is an ultra-low noise, low dropout (LDO) linear regulator that operates from 2.2V to 5.5V and provides output current up to 150mA (LD501L), 200mA (LD501M), or 250mA (LD501P). The low dropout voltage—70mV at 150mA load (LD501L), 94mV at 200m.

Image gallery

TAGS

LD501
