ATH30, ATH30-1, 3.3-V Input Non-Isolated Wide-Output Adjust Power Module

ATH06T033 Series *3.3-V Input 6-A, 3.3-V Input Non-Isolated Wide-Output Adjust Power Module REVISION 00 (01DEC2003) .
The ATH06T033 series is one of the smallest non-isolated power modules that features Auto-Track™.

datasheet Preview Page 1 from Datasheet4u.com

ATH30-1_Astec.pdf

ATH30 Datasheet Preview — This datasheet PDF includes multiple part numbers: ATH30, ATH30-1. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

ATH30, ATH30-1

Manufacturer:

Astec

File Size:

568.31 KB

Description:

3.3-V Input Non-Isolated Wide-Output Adjust Power Module

Note:

This datasheet PDF includes multiple part numbers: ATH30, ATH30-1.
Please refer to the document for exact specifications by model.

Features

* Up to 6-A Output Current
* 3.3-V Input Voltage
* Wide-Output Voltage Adjust (0.8 V to 2.5 V)
* Efficiencies up to 94 %
* 103 W/in³ Power Density
* On/Off Inhibit
* Pre-Bias Startup
* Under-Voltage Lockout
* Operating Temp:

Applications

* where space, performance, and a power-up sequencing capability are important attributes. The product provides high-performance step-down conversion from a 3.3-V input bus voltage. The output voltage of the ATH06T033 can be set to any voltage over the range, 0.8 V to 2.5 V, using a single resistor. O
