HT10X21-311
DESCRIPTION
OF CHANGES
Initial Release
DATE
PREPARED
P.Y.Lee
SPEC. NUMBER S864-1175 B3-002-A (2/3)
SPEC. TITLE HT10X21-311 Product Specification
PAGE 2 OF 22 A4(210 X 297)
PRODUCT GROUP TFT-LCD PRODUCT
REV. O
ISSUE DATE 2004.03.04
Contents
No 1.0 2.0 3.0 4.0 5.0 6.0 7.0 8.0 9.0 10.0 11.0 12.0 13.0 General Description
Absolute Maximum Ratings Electrical Specifications Optical Specifications Interface Connection Signal Timing Specifications Signal Timing Waveforms of interface signal (DE mode) Input Signals, Display Colors & Gray Scale of Colors Power Sequence Mechanical Characteristics Reliability Test Handling & Cautions Appendix Item Page 4 5 6 7 9 11 13 14 15 16 17 18 19
SPEC. NUMBER S864-1175 B3-002-A (3/3)
SPEC. TITLE HT10X21-311 Product Specification
PAGE 3 OF 22
A4(210 X 297)
PRODUCT GROUP TFT-LCD PRODUCT
1.0 GENERAL DESCRIPTION
1.1 Introduction
REV. O
ISSUE DATE 2004.03.04
HT10X21-311 is a color active matrix TFT LCD module using amorphous silicon...
