5.0SMDJ43CA, 5.0SMDJ5.0A - Transient Voltage Suppressor Diode

BOURNS

5.0SMDJ43CA Datasheet Preview — This datasheet PDF includes multiple part numbers: 5.0SMDJ43CA, 5.0SMDJ5.0A. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	5.0SMDJ43CA, 5.0SMDJ5.0A
Manufacturer	BOURNS
File Size	185.68 KB
Description	Transient Voltage Suppressor Diode
Datasheet	5.0SMDJ5.0A-BOURNS.pdf
Note	This datasheet PDF includes multiple part numbers: 5.0SMDJ43CA, 5.0SMDJ5.0A. Please refer to the document for exact specifications by model.

5.0SMDJ43CA Product details

Description

UL File Number: E153537 Electrical Characteristics (@ TA = 25 °C Unless Otherwise Noted) Parameter Symbol Value Minimum Peak Pulse Power Dissipation (Tp = 1 ms) (Note 1,2) Peak Forward Surge Current 8.3 ms Single Half Sine Wave Superimposed on Rated Load (JEDEC Method) (Note 3,4) PPK IFSM 5000 300 Steady State Power Dissipation @ TL = 50 °C Maximum Instantaneous Forward Voltage @ IPP = 100 A (For Unidirectional Units Only) PM(AV) 6.5 VF 5 Operating Temperature Range TJ -55 to +1

Features

RoHS compliant.
and halogen free.
Surface mount SMC package.
Standoff voltage: 5 to 170 volts.
Peak Pulse Power: 5000 watts.
Typical temperature coefﬁcient: ΔVBR = 0.1 % x VBR @ 25 °C x ΔT 5.0SMDJ Transient Voltage Suppressor Diode Series General Information Portable communications, computing and video equipment manufacturers are challenging the semiconductor industry to develop increasingly higher power density circuit protection components. Bourns offe.
