BP2865BJ, BP2865SJ Datasheet - BPS

BP2865BJ Non-isolated Buck Offline LED Driver

BP2865XJ is a high precision Buck constant current LED driver. The device operates in critical conduction mode and is suitable for 85Vac~265Vac universal input offline LED lighting. The BP2865XJ integrates a 500V power MOSFET, with proprietary MOSFET driving technique. It doesn’t need VCC capacitor .

BP2865BJ Features

* No VCC Capacitor and Startup Resistor

* Integrated HV JFET for IC Power Supply

* Internal 500V Power MOSFE

BP2865SJ-BPS.pdf

This datasheet PDF includes multiple part numbers: BP2865BJ, BP2865SJ. Please refer to the document for exact specifications by model.
BP2865BJ Datasheet Preview Page 2

Datasheet Details

Part number:

BP2865BJ, BP2865SJ

Manufacturer:

BPS

File Size:

234.86 KB

Description:

Non-isolated buck offline led driver.

Note:

This datasheet PDF includes multiple part numbers: BP2865BJ, BP2865SJ.
Please refer to the document for exact specifications by model.
