BP2867DJ Datasheet - BPS

Non-isolated Buck Offline LED Driver

BP2867DJ Features

* No VCC Capacitor and Startup Resistor

* Integrated HV JFET for IC Power Supply

* Internal 500V Power MOSFET

* Critical Conduction Mode Operation

* ±5% LED Output Current Accuracy

* Configurable OVP by Rovp resistor

* LED Short Protection

* Thermal Regulation Functio

BP2867DJ General Description

BP2867XJ is a high precision Buck constant current LED driver. The device operates in critical conduction mode and is suitable for 85Vac~265Vac universal input offline LED lighting. The BP2867XJ integrates a 500V power MOSFET, with proprietary MOSFET driving technique. It doesn’t need VCC capacitor .

BP2867DJ Datasheet (238.32 KB)

Preview of BP2867DJ PDF

Datasheet Details

Part number:

BP2867DJ

Manufacturer:

BPS

File Size:

238.32 KB

Description:

Non-isolated buck offline led driver.
