BP3316 - PSR Single-Stage APFC Offline LED Driver

BPS

BP3316 Description

BP3316 PSR Single-Stage APFC Offline LED Driver .
The BP3316 is a high precision primary-side regulation driver with single stage Active PFC, specially designed for universal input offline flyback or.

BP3316 Features

* Single-Stage Active PFC for High Power Factor and Low THD
* Primary Side Control Constant Current Operation, No Opto-Coupler required
* Integrated 650V Power MOSFET
* ±3% LED Current Accuracy
* Excellent Line and Load Regulation
* Critical Conduction Mode Operation
* Ul

BP3316 Applications

* E27/ GU10 LED Bulb, Spot Light
* PAR30, PAR38 LED Lamp
* T8/T10 LED String
* Other LED Lighting NP NS AC NA BP3316 2 VCC DRAIN 5 3 FB DRAIN 6 1 COMP 4 CS GND 7 GND 8 Figure 1. Typical application circuit for BP3316 BP3316_EN _DS_Rev.1.0 www. bpsemi. com 1 Bright Power S

📥 Download Datasheet

BP3316 Datasheet Preview — Preview of BP3316 PDF

Datasheet Details

Part number: BP3316
Manufacturer: BPS
File Size: 454.04 KB
Datasheet: BP3316-BPS.pdf
Description: PSR Single-Stage APFC Offline LED Driver
