MPC508A (MPC509A) Single-Ended 8-Channel/Differential 4-Channel CMOS ANALOG MULTIPLEXERS

The MPC508A is an 8-channel single-ended analog multiplexer and the MPC509A is a 4-channel differential multiplexer. The MPC508A and MPC509A multiplexers have input overvoltage protection. Analog input voltages may exceed either power supply voltage without damaging the device or disturbing the sign.

MPC508A Features

* q q q q q q ANALOG OVERVOLTAGE PROTECTION: 70Vp-p NO CHANNEL INTERACTION DURING OVERVOLTAGE BREAK-BEFORE-MAKE SWITCHING ANALOG SIGNAL RANGE: ±15V STANDBY POWER: 7.5mW typ TRUE SECOND SOURCE In 1 Out 1kΩ In 2 1kΩ In 8 1kΩ The MPC508A and MPC509A are fabricated with Burr-Brown’s dielectrically isolat
