BZX55C100 Datasheet - CDIL

BZX55C100 SILIICON PLANAR ZENER DIODES

Power Dissipation (1) Surge Power Dissipation Pulse Width=10 ms Junction Temperature Storage Temperature Thermal Resistance Junction to Ambient (1) (1) On infinite heatsink with 4mm lead length. SYMBOL PTA PS Tj Tstg Rth(j-a) VALUE 500 5.0 175 - 65 to +175 0.3 Forward Voltage @ IF=200mA (BZX55C 2.

BZX55C100 Datasheet (92.77 KB)

Preview of BZX55C100 PDF
BZX55C100 Datasheet Preview Page 2 BZX55C100 Datasheet Preview Page 3

Datasheet Details

Part number:

BZX55C100

Manufacturer:

CDIL

File Size:

92.77 KB

Description:

Siliicon planar zener diodes.
