MM3Z4V7 Features
* Total power dissipation : max. 300 mW Small plastic package suitable for surface mounted design Tolerence approximately ±5% AEC-Q101 Qualified Halogen and Antimony Free(HAF), RoHS compliant ABSOLUTE MAXIMUM RATINGS (Ta = 25°C) PARAMETER Power Dissipation Operating Junction Temperature Range Storage
Datasheet Details
MM3Z4V7, MM3Z2V0
CDIL
1.80 MB
Silicon planar zener diodes.
This datasheet PDF includes multiple part numbers: MM3Z4V7, MM3Z2V0.
Please refer to the document for exact specifications by model.
