CP2021 2.5W Qi V1.2.4-Compliant Wireless Power Receiver

CP2021 Description

CP2021 2.5W Qi V1.2.4-Compliant Wireless Power Receiver and Power Supply * * * * * * * * .
CP2021 is a single-chip, advanced, flexible, secondary-side device for wireless power transfer in portable applications capable of providing up.

CP2021 Features

* Integrated Wireless Power Supply Receiver Solution - High Efficiency Full Synchronous Rectifier - Output Voltage Conditioning - WPC Qi V1.2.4 Compliant communication - Control - Single IC Required Between RX Coil and Output
* WPC Qi V1.2.4 FOD Function
* Support I2C Internal Register

CP2021 Applications

* - Optimize the dynamic efficiency for full load output
* Rectifier Overvoltage Clamp (VOVP=15V)
* Support 20 V Maximum Input
* Over Temperature, Over Voltage and Over Current Protection
* Open Drain LED Output Indication
* Multifunction NTC and Temperature Monitoring, Charge Com

📥 Download Datasheet

Preview of CP2021 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
CP2021
Manufacturer
COPO
File Size
1.41 MB
Datasheet
CP2021-COPO.pdf
Description
2.5W Qi V1.2.4-Compliant Wireless Power Receiver
