CRMM6602C
Features
- Uses CRM(CQ) advanced Trench technology
- Extremely low on-resistance RDS(on)
- Excellent Qgx RDS(on) product(FOM)
- plementary N-ch and P-ch MOSFET
Applications
- Motor drive
30V plementary Power MOSFET
Product Summary
Symbol
N-Ch
VDS RDS(on) typ.
30V 25mΩ
5A
P-Ch -30V 60mΩ -3.5A
100% DVDS Tested 100% Avalanche Tested
Package Marking and Ordering Information
Part #
Marking
Package
SOT-23-6
Absolute Maximum Ratings
Parameter
Drain-source voltage Continuous drain current TC = 25°C (Silicon limit) Continuous drain current TC = 25°C (Package limit) Pulsed drain current (TC = 25°C, tp limited by Tjmax) Avalanche energy, single pulse (L=0.5m H, Rg=25Ω) Gate-Source voltage Power dissipation (TC = 25°C) Operating junction and storage temperature
Packing Reel Size
Taping
N/A
Tape Width N/A
Qty 3000pcs
Symbol
VDS ID ID ID pulse EAS VGS Ptot Tj , T stg
Maximum
N-Ch P-Ch
-30
-3.5
-3.5...
