CRMQTL0306A Datasheet, Mosfet, CRM Microelectronics

CRMQTL0306A Features

• Mosfet l 30V, 52A D RDS(ON) Typ = 4.1mΩ @ VGS = 10V RDS(ON) Typ = 6.2mΩ @ VGS = 4.5V l Advanced Trench Technology s l Excellent RDS(ON) and Low Gate Charge ic l Lead Free n l 100% UIS TESTED

PDF File Details

Part number:

CRMQTL0306A

Manufacturer:

CRM Microelectronics

File Size:

572.46kb

Download:

📄 Datasheet

Description:

N-channel power mosfet. Features l 30V, 52A D RDS(ON) Typ = 4.1mΩ @ VGS = 10V RDS(ON) Typ = 6.2mΩ @ VGS = 4.5V l Advanced Trench Technology s l Excellent

CRMQTL0306A Application

• Applications including compliance with all laws, regulations and safety requirements or standards. “Typical” parameters which provided in datasheet
