Features High Temperature (302°F) Side Exit Sensor Popular, Proven Side Exit Sensor for Standard High Temperature Applications Resistant to Temperatures Up to 302°F (150°C) 6C version has armor, Heavy Duty Teflon® Jacketed Cable with Braided Shield for Demanding Applications ±80 g, Peak Dynamic Range Connector Pin Polarity A (+) Signal / Power B (+) mon Armored Integral Cable Conductor Polarity Red (+) Signal / Power Black (-) mon Shield Cable Drain Wire AC208-6C Heavy Duty Armored Integral Cable Conductor Polarity Red (+) Signal / Power Black (-) mon Shield Cable Drain Wire Specifications Part Number Sensitivity (±10%) Frequency Response (±3d B) Frequency Response (±10%) Dynamic Range Electrical Settling Time Voltage Source (IEPE) Constant Current Excitation Spectral Noise @ 10 Hz Spectral Noise @ 100 Hz Spectral Noise @ 1000 Hz Output Impedance Bias Output Voltage Case Isolation Ordering Information Standard Metric AC208 M/AC208 100 m V/g 60-480,000 CPM 1,0-8000 Hz 120-180,000 CPM 2,0-3000 Hz ± 80 g, peak <2.5 seconds 18-30 VDC 2-10 m A 8 µg/√Hz 0.82 µg/√Hz 0.3 µg/√Hz <100 ohm 10-14 VDC >108 ohm Specifications Environmental Temperature Range Maximum Shock Protection Electromagnetic Sensitivity Sealing Physical Sensing Element Sensing Structure Weight Case Material Mounting Hole Connector (non-integral) Resonant Frequency Mounting Torque Mounting Hardware Calibration Certificate Standard AC208-1A (1/4-28 Captive Bolt) Stock Product - / (1/4-28 Captive Bolt) Build To Order (length in...
