CM6800T Datasheet - Champion Microelectronic

CM6800T EPA/85+ PFC+PWM COMBO CONTROLLER

CM6800T is a turbo-speed PFC and a Green PWM controller. It is designed to further increase power supply efficiency while using the relatively lower 380V Bulk Capacitor value. Switching to CM6800T from your existing CM6800 family boards can gain the following advanced performances: 1.) Hold Up time .

CM6800T Features

* ‹ Patents Pending ‹ Pin to pin compatible with CM6802 family, CM6800 family, and ML4800 family ‹ 23V Bi-CMOS process ‹ Designed for EPA/85+ efficiency ‹ Digitized Exactly 50% Maximum PWM Duty Cycle ‹ All high voltage resistors can be greater than 4.7 Mega ohm (4.7 Mega to 8 Mega ohm) to improve the

CM6800T Datasheet (843.09 KB)

Preview of CM6800T PDF

Datasheet Details

Part number:

CM6800T

Manufacturer:

Champion Microelectronic

File Size:

843.09 KB

Description:

Epa/85+ pfc+pwm combo controller.
